Modern electronics — especially forward-facing sonar and multiple graphs — demand clean, dedicated power. Graph Power is a complete plug-and-play wiring system that routes high-quality power from the battery to console and bow without sharing circuits or creating interference. Choose the size that fits your rig: 10 ft for tillers and small boats, 16–18 ft for mid-size console boats, or 19–22 ft for full-size bass and multi-species boats.
Today's forward-facing sonar and multi-graph setups are sensitive to voltage drop and electrical noise. Connect-Ease clean-power wiring gives each device its own fused, dedicated circuit back to a clean 12V house battery — no shared trolling motor circuits and no piggy-backed ring terminals — so screens stay crisp, sonar stays quiet and units don't reboot under load.
Compatible electronics and accessories: Humminbird HELIX, SOLIX, APEX and MEGA Live 2; Garmin ECHOMAP UHD2, GPSMAP and LiveScope Plus / XR (GLS 10 black box); Lowrance HDS PRO, HDS Live, Elite FS and ActiveTarget 2; Raymarine Axiom and Element.
System voltage: 12V house battery (lithium compatible). Recommended batteries: Dedicated 12V house battery: 12.8V LiFePO4 (20–50Ah) recommended for forward-facing sonar; AGM also works. Up to 16V lithium supported where noted. Amperage and protection: 30A fuse at the battery; 3A or 5A fuse at each graph, transducer box or FFS black box as your electronics maker specifies.
Key features
- Three sizes: 10 ft, 16–18 ft and 19–22 ft
- Console and bow backbones with multiple fused drops (16–18 and 19–22 ft)
- 8-gauge marine-grade sheathed wire
- Easy-feed design for clean routing
- No cutting, splicing or soldering after install
- Lithium compatible
Compatibility & specs
| Compatible fish finders, graphs & FFS | Humminbird HELIX, SOLIX, APEX and MEGA Live 2; Garmin ECHOMAP UHD2, GPSMAP and LiveScope Plus / XR (GLS 10 black box); Lowrance HDS PRO, HDS Live, Elite FS and ActiveTarget 2; Raymarine Axiom and Element |
| Recommended voltage | 12V house battery (lithium compatible) |
| Amperage / fuse / breaker | 30A fuse at the battery; 3A or 5A fuse at each graph, transducer box or FFS black box as your electronics maker specifies |
| Battery types | Dedicated 12V house battery: 12.8V LiFePO4 (20–50Ah) recommended for forward-facing sonar; AGM also works. Up to 16V lithium supported where noted |
Specs come from the product listing. Always follow your trolling motor or electronics maker's manual for final fuse and breaker sizing.
Frequently asked questions
Common questions about the Graph Power Clean Power Wiring Kit — Choose Your Boat Size.
10 ft for tillers, kayaks and small boats; 16–18 ft for mid-size console boats; 19–22 ft for full-size bass and multi-species boats.
Screen flicker, sonar noise, unit reboots and voltage drop caused by shared or undersized wiring.
